Earthing Beryllium Copper Alloy C17200 strip Brass Surface

Name: Earthing Beryllium Copper Alloy C17200 strip Brass Surface
Brand: jinshunlai
Price: 1 USD

Earthing Beryllium Copper Alloy C17200 strip Brass Surface Manufactures

Brand Name : jinshunlai

Model Number : 0.1nm-900nm

Certification : ISO, AISI, ASTM, GB, EN, DIN

Place of Origin : china

MOQ : 1kg

Price : Contact Us

Payment Terms : L/C, T/T , Western Union

Supply Ability : 90000ton

Delivery Time : 5day

Coefficient of Thermal Expansion : 17.2 μm/m°C

Density : 8.9 g/cm3

Electrical Resistivity : 0.15 μΩm

Elongation : 20 %

Fatigue Strength : 150 MPa

Hardness : HB 90

Material : Chromium Zirconium Copper

Melting Point : 1084 °C

Modulus of Elasticity : 120 GPa

Poisson's Ratio : 0.35

Shear Modulus : 45 GPa

Tensile Strength : 360 MPa

Thermal Conductivity : 170 W/mK

Thickness : Sheet

Yield Strength : 200 MPa

Packaging Details : Waterproof Paper, Steel Strip Packed and other Standard Export Seaworthy Package, or customized package

Contact Now

Typical Physical Properties of BrBNT1.9 (Qbe1.9) Copper Beryllium Alloy:
Density (g/cm3): 8.25
Elastic Modulus(Gpa): 130
Electrical Conductivity: 22-28% IACS
Thermal Expansion Coefficient(m/m℃): 17.5x10-6

Thermal Conductivity(25℃): 105W/m℃
Melting Point (°C): 870

echanical And Electrical Properties of BrBNT1.9 (Qbe1.9) Copper Beryllium Strip:

Name	Temper	Thickness (mm)	Tensile Strength	Hardness	Elongation (min)

			MPa	HV	Percent
Qbe1.9	Soft	<0.15	>390	<120	>30%
		0.15~0.25	390~590
		>0.25	390~590
	Hard	<0.15	>590	>160	>3%
		0.15~0.25	590~880
		>0.25	640~930
	After Ageing (Soft)	<0.15	>1080	>330	>2%
		0.15~0.25	1080~1470
		>0.25	1130~1470
	After Ageing (Hard)	<0.15	>1080	>360	>1.5%
		0.15~0.25	1130~1570
		>0.25	1170~1570
